- Comply with GB12190-90 level C(FS-C) standard .
- Magnetic field: 14KHz ≥70dB 150KHz ≥95dB.
- Electric field: 200KHz ~1GHz ≥ 100dB.
- Plane wave: 50MHz ~ 1GHz ≥ 100dB.
- Microwave: 1GHz ~10GHz ≥ 95 dB.
- Level B(FS-B)150KHz~930MHz≥80 dB.
- Shielded enclosure: Airtight enclosure welded by cold rolled steel plate . Surface finishing: galvanizing, powder coating and other anticorrosive treatment.
- Shield door: Welded by cold rolled steel plate and shield reed .
- Filter: Power filter with wide suppressed frequency band and high insertion loss.
- Wave-guide window: Honeycomb style window with mini aerofoil fan on the top plate. Exhaust air rate of each fan: 1.4 cbm/min.
- Others: Optional transmission interface and socked outlet as required .
- Prevente the information leakage of computer, network server, switchboard,etc.
- Prevented the interference of electromagnetic waves .
- Easy operation, reliable.
|
Part No |
External |
External |
External |
Internal |
Internal |
Internal |
|
32U |
700mm |
650mm |
1850mm |
650mm |
500mm |
1500mm |
|
37U |
700mm |
650mm |
2000mm |
650mm |
500mm |
1600mm |
|
42U |
700mm |
650mm |
2000mm |
650mm |
500mm |
1800mm |
Remarks : Can be made as customer required
☆=Colors A=Black(RAL9004) B=Gray(RAL7044)
