- Comply with ANSI/EIARS-310-D, DIN41491; PART1, IEC297-2, DIN41494; PART7, GB/T3047.2-92 standard.
- Compatible with metric ETSI and 19 inch international standard.
APPLICATION
-
Widely used in network system, educational system, broadcasting system and telecommunication system. Suitable for placing server
computer and precision electronic equipments.
MATERIALS
-
Cool rolled steel
Thickness: Front and bottom beams:1.5mm
Else in 1.2mm
Tempered smoky-gray glass with thickness of 5mm.
- Modular design, easily assemble and disassembl for delivery, low cost.
- Various optional accessories according to requirements.
- Static load: 150kg.
- Lever of protection: IP20.
- Surface finish: Degreased, acid cleaned, phosphoric, water cleaned,electro-static powder coating, meet ROHS standard.
- Optional color: black/gray.
- Optional accessories.
| Part No |
Capacity/U |
Width/mm |
Depth/mm |
Height/mm |
CM/Width/m |
CM/Depth/m |
CM/Height/m |
Volume/CBM |
|
DRB18-66-☆ |
18U |
600 |
600 |
1040 |
0.63 |
0.31 |
1.00 |
0.1953 |
|
DRB22-66-☆ |
22U |
600 |
600 |
1222 |
0.63 |
0.31 |
1.18 |
0.2305 |
|
DRB27-66-☆ |
27U |
600 |
600 |
1444 |
0.63 |
0.31 |
1.40 |
0.2734 |
|
DRB32-66-☆ |
32U |
600 |
600 |
1555 |
0.63 |
0.31 |
1.63 |
0.3183 |
|
DRB37-66-☆ |
37U |
600 |
600 |
1666 |
0.63 |
0.31 |
1.85 |
0.3713 |
|
DRB42-66-☆ |
42U |
600 |
600 |
1888 |
0.63 |
0.31 |
2.07 |
0.4043 |
|
DRB47-66-☆ |
47U |
600 |
600 |
2110 |
0.63 |
0.31 |
2.29 |
0.4472 |
☆=Colors A=Black(RAL9004) B=Gray(RAL7044)
