- Comply with ANSI/EIARS-310-D, DIN41491; PART1, IEC297-2, DIN41494; PART7, GB/T3047.2-92 standard. Compatible with metric ETSI and 19 inch international standard.
APPLICATION
-
Widely used in network system, educational system, broadcasting system and telecommunication system. Suitable for placing server
computer and precision electronic equipments.
MATERIALS
-
Cool rolled steel
Thickness: Vertical rail:1.5mm
Else in 1.2mm
Tempered smoky-gray glass with thickness of 5mm.
- Exquisite design with precise craftsmanship.
- International popular smoky-gray glass front door.
- Easily be mounted on wall, or placed on floor after installed castor or feet.
- Loading capacity: 60KG.
- Top and bottom wiring channel could be closed.
- Removable front door and side panel, easily installing and maintaining.
- Surface finish: Degreased, acid cleaned, phosphoric, water cleaned,electro-static powder coating, meet ROHS standard.
- Optional color: black/gray.
- Optional accessories.
| Part No |
Capacity/U |
Width/mm |
Depth/mm |
Height/mm |
CM/Width/m |
CM/Depth/m |
CM/Height/m |
Volume/CBM |
|
WCB06-645-*☆ |
6U |
600 |
450 |
368 |
0.67 |
0.52 |
0.43 |
0.15 |
|
WCB09-645-*☆ |
9U |
600 |
450 |
501 |
0.67 |
0.52 |
0.56 |
0.20 |
|
WCB12-645-*☆ |
12U |
600 |
450 |
635 |
0.67 |
0.52 |
0.70 |
0.24 |
|
WCB15-645-*☆ |
15U |
600 |
450 |
769 |
0.67 |
0.52 |
0.83 |
0.29 |
|
WCB18-645-*☆ |
18U |
600 |
450 |
901 |
0.67 |
0.52 |
0.96 |
0.33 |
|
WCB22-645-*☆ |
22U |
600 |
450 |
1082 |
0.67 |
0.52 |
1.14 |
0.40 |
|
WCB06-66-*☆ |
6U |
600 |
600 |
368 |
0.67 |
0.67 |
0.43 |
0.19 |
|
WCB09-66-*☆ |
9U |
600 |
600 |
501 |
0.67 |
0.67 |
0.56 |
0.25 |
|
WCB12-66-*☆ |
12U |
600 |
600 |
635 |
0.67 |
0.67 |
0.70 |
0.31 |
|
WCB15-66-*☆ |
15U |
600 |
600 |
769 |
0.67 |
0.67 |
0.83 |
0.37 |
|
WCB18-66-*☆ |
18U |
600 |
600 |
901 |
0.67 |
0.67 |
0.96 |
0.43 |
|
WCB22-66-*☆ |
22U |
600 |
600 |
1082 |
0.67 |
0.67 |
1.14 |
0.51 |
* = Front door(A=Steel Casement Door B=B=Smoky-grey glass door C=Smoky-gray glass door with frame punche
D =Perforation steel door with high ventilation level(hexagonal type))
☆=Colors A=Black(RAL9004) B=Gray(RAL7044)
