Wall-mount 110 wiring blocks create compact, adaptable 110 termination field for voice and data by mounting 110 wiring bases to the wall or a backboard. Bases come in 50 pair densities. The 50-pair bases may be ordered with or without standoff legs which provide more room behind the base for cable.
- Type : 50 pairs rack mount 110 wiring block Available with legs or without legs to the wiring base.
- Easy to adjust , easy to embed wires in Wiring blocks are designed to support voice and high-speed data application.
- Offering a reliable and economical high -density system.
- The terminal blocks accommodate 22-26 AWG with a insulation diameter of 0.4-0.64 mm.
- IDC contact material : phosphor bronze with tin plating over nickel Available with T568 A .T568 B wiring pattern.
|
Part number |
Description |
standard color |
Inner box |
Carton |
Carton measurement |
Carton weight |
|
WB050-A3W |
50 pair wiring block without legs |
Beige |
2PCS |
20PCS |
L 54cm×W 49cm×H 22cm |
5.00KG |
