- Comply with ANSI/EIARS-310-D, DIN41491; PART1, IEC297-2, DIN41494; PART7, GB/T3047.2-92 standard. Compatible with metric ETSI and 19 inch international standard.
APPLICATION
- Mainly applied in Finance, Securities and Data Centre, etc.
MATERIALS
- Cold-rolled steel sheet. Thickness for hanger rail 2.0 mm, support beam 1.5mm, sliding door 1.2 mm. Heavy duty nylon silent pulley.
- Surface finish: degreasing, pickling, phosphoric, powder coating. The thickness of powder coating is 80μm-100μm, complying with ROHS.
- By adopting heavy duty nylon silent pulley and aluminum alloy hanger rail,the sliding door can be opened and closed easily. And the locks on the door are convenient for people managing the cold pool channel.
- The material of sliding door is double-deck cold-rolled sheet metal which make sure a good intensity of the door; And the middle of the door is made up of clear tempering glass which allow the outside people checking the situation of inside channel.
- The support beam on the top of cold pool channel is used for placing tempering glass. The thickness of the support beam is 1.5mm.
|
Part number |
Description |
Applications |
|
NCH01-612 |
Standard 600X1200 cold pool glass roof and mounting bracket |
Tempered glass top |
|
NCH01-812 |
Standard 800X1200 cold pool glass roof and mounting bracket |
Tempered glass top |
|
NCH02-42U6-☆ |
Standard 42U600 wide sliding door cold pool |
Contains installation components and two sliding doors |
|
NCH02-47U6-☆ |
Standard 42U600 wide sliding door cold pool |
Contains installation components and two sliding doors |
☆ = Colors A= Black(RAL9004) B=Gray(RAL7044)
