- Comply with ANSI/EIARS-310-D, DIN41491; PART1, IEC297-2, DIN41494; PART7, GB/T3047.2-92 standard. Compatible with metric ETSI and 19 inch international standard.
APPLICATION
- Widely applied in finance, securities and data center; adopted by the professional servers’ network providers as IBM, SUN, HP, COMPAQ, DELL etc.
MATERIALS
- Cold-rolled steel sheet. Thickness for frame 2.0mm, mounting rail 2.0mm, side panel 1.5mm,fixed shelf 1.5mm.
- Surface finish: degreasing, pickling, phosphoric, powder coating . The thickness of powder coating is 80μm-100μm .
- Curved perforated front door and double-section rear door enable equipment protection, reliable operation with entilation rate above 80% .
- Double-section side panels, each panel can be easily assembled separately.
- Top and bottom wiring channel can be closed and adjustable.
- Backside with a pair of vertical cable management .
- Mounting rail with U mark.
- Efficient and solid cabinet connection.
- With earthing kits.
- Advanced lock .
- Optional plinth to meet under-base wiring, ventilation and rat-proof .
- Adjustable feet and heavy duty castors are available at the same time , static loading: 1000KG .
- Full range of optional accessories.
| Part No |
Capacity/u |
Width/mm |
Depth/mm |
Height/mm |
CMwidth/m |
CM Depth/m |
CM Heigh/m |
Volume/CBM |
|
NCF37-66-*#☆ |
37U |
600 |
700 |
1800 |
0.65 |
0.75 |
1.8 |
0.7605 |
|
NCF37-68-*#☆ |
37U |
600 |
900 |
1800 |
0.65 |
0.95 |
1.8 |
0.9945 |
|
NCF37-610-*#☆ |
37U |
600 |
1100 |
1800 |
0.65 |
1.15 |
1.8 |
1.2285 |
|
NCF37-88-*#☆ |
37U |
800 |
900 |
1800 |
0.85 |
0.95 |
1.8 |
1.3005 |
|
NCF37-810-*#☆ |
37U |
800 |
1100 |
1800 |
0.65 |
1.15 |
1.8 |
1.6065 |
|
NCF42-66-*#☆ |
42U |
600 |
700 |
2000 |
0.65 |
0.75 |
2.0 |
0.845 |
|
NCF42-68-*#☆ |
42U |
600 |
900 |
2000 |
0.65 |
0.95 |
2.0 |
1.105 |
|
NCF42-610-*#☆ |
42U |
600 |
1100 |
2000 |
0.65 |
1.15 |
2.0 |
1.365 |
|
NCF42-88-*#☆ |
42U |
800 |
900 |
2000 |
0.85 |
0.95 |
2.0 |
1.445 |
|
NCF42-810-*#☆ |
42U |
800 |
1100 |
2000 |
0.85 |
1.15 |
2.0 |
1.785 |
|
NCF47-66-*#☆ |
47U |
600 |
700 |
2200 |
0.65 |
0.75 |
2.2 |
0.9295 |
|
NCF47-68-*#☆ |
47U |
600 |
900 |
2200 |
0.65 |
0.95 |
2.2 |
1.2155 |
|
NCF47-610-*#☆ |
47U |
600 |
1100 |
2200 |
0.65 |
1.15 |
2.2 |
1.5015 |
|
NCF47-88-*#☆ |
47U |
800 |
900 |
2200 |
0.85 |
0.95 |
2.2 |
1.5895 |
|
NCF47-810-*#☆ |
47U |
800 |
1100 |
2200 |
0.85 |
1.15 |
2.2 |
1.9635 |
*=Front door (A=steel casement door B=Curved perforated door L=double swing steel door N=Smoky-gray glass door with both sides punched)
#=Rear door ((A=steel casement door B=Curved perforated door L=double swing steel door N=Smoky-gray glass door with both sides punched))
☆=Colors A=Black(RAL9004),B=Gray(RAL7044)
