- Comply with ANSI/EIARS-310-D, DIN41491; PART1, IEC297-2, DIN41494; PART7, GB/T3047.2-92 standard. Compatible with metric ETSI and 19 inch international standard.
APPLICATION
- Widely applied in finance, securities and data center; adopted by the professional servers’ network providers as IBM, SUN, HP, COMPAQ, DELL etc.
MATERIALS
- Cold-rolled steel sheet. Thickness for frame (Nine-fold section steel)1.5mm, mounting rail 2.0mm, side panel 1.5mm.
- Surface finish: degreasing, pickling, phosphoric, powder coating. The thickness of powder coating is 80μm-100μm, complying with ROHS.
- Curved perforated front door and double-section rear door enable equipment protection, reliable operation with entilation rate above 80% .
- Nine-fold section steel for the frame.
- Mounting rail and mounting angle finish: Electric galvanizing.
- Top and bottom wiring channel can be closed and adjusted.Bottom plate with earthing wire.
- Optional plinth to meet under-base wiring, ventilation and rat-proof.
- Advanced lock. Efficient and solid cabinet connection.
- Adjustable feet and heavy duty castors are available at the same time,static loading: 1000KG.
- Full range of optional accessories.
- Mounting rail with U mark.
| Part No |
Capacity/u |
Width/mm |
Depth/mm |
Height/mm |
CMwidth/m |
CM Depth/m |
CM Heigh/m |
Volume/CBM |
|
NCC37-66-*#☆ |
37U |
600 |
700 |
1800 |
0.65 |
0.65 |
1.8 |
0.7605 |
|
NCC37-68-*#☆ |
37U |
600 |
800 |
1800 |
0.65 |
0.85 |
1.8 |
0.9945 |
|
NCC37-610-*#☆ |
37U |
600 |
1000 |
1800 |
0.65 |
1.05 |
1.8 |
1.2285 |
|
NCC37-88-*#☆ |
37U |
800 |
800 |
1800 |
0.85 |
0.85 |
1.8 |
1.3005 |
|
NCC37-810-*#☆ |
37U |
800 |
1000 |
1800 |
0.85 |
1.05 |
1.8 |
1.6065 |
|
NCC42-66-*#☆ |
42U |
600 |
600 |
2000 |
0.65 |
0.65 |
2.0 |
0.845 |
|
NCC42-68-*#☆ |
42U |
600 |
800 |
2000 |
0.65 |
0.85 |
2.0 |
1.105 |
|
NCC42-610-*#☆ |
42U |
600 |
1000 |
2000 |
0.65 |
1.05 |
2.0 |
1.365 |
|
NCC42-88-*#☆ |
42U |
800 |
800 |
2000 |
0.85 |
0.85 |
2.0 |
1.445 |
|
NCC42-810-*#☆ |
42U |
800 |
1000 |
2000 |
0.85 |
1.05 |
2.0 |
1.785 |
|
NCC47-66-*#☆ |
47U |
600 |
600 |
2200 |
0.65 |
0.65 |
2.2 |
0.9295 |
|
NCC47-68-*#☆ |
47U |
600 |
800 |
2200 |
0.65 |
0.85 |
2.2 |
1.2155 |
|
NCC47-610-*#☆ |
47U |
600 |
1000 |
2200 |
0.65 |
1.05 |
2.2 |
1.5015 |
|
NCC47-88-*#☆ |
47U |
800 |
800 |
2200 |
0.85 |
0.85 |
2.2 |
1.5895 |
|
NCC47-810-*#☆ |
47U |
800 |
1000 |
2200 |
0.85 |
1.05 |
2.2 |
1.9635 |
*=Front door A=steel casement door D=Perforation steel door F=double swing steel door(perforated) H=curved concavo-convexperforation steel door( hexagonal Type) I=concavo-convex
perforation steel doo ( hexagonal Type) J=double swing steel door
#=Rear door A=steel casement door D=Perforation steel door F=double swing steel door(perforated) H=curved concavo-convexperforation steel door( hexagonal Type) I=concavo-convex
perforation steel doo ( hexagonal Type) J=double swing steel door
☆ = Colors A= Black(RAL9004) B=Gray(RAL7044)
